A digital workshop for tangible ideas

From a flat sheet
to your next idea.

Design boxes, organizers and paper forms.
Resize, fold, brand and export.

Start makingExplore the atlas
+Real geometry. Editable dimensions. Files you can make.
F / A — 001LIVE PARAMETRIC MODEL
+
+
FORMATLAS · 001
THE FLAT FORM
The everyday cartonStraight tuck · Paperboard80 × 60 × 40 mmINTERNAL DIMENSIONS
FLATFOLDED
01

Fit my product

Start with what goes inside.

02

Use my sheet

Find the possibilities in your material.

03

Fill this space

Give everything a place of its own.

04

Build a matching kit

One idea. Every piece connected.

The atlas / selected forms

Small beginnings. Endless directions.

View every form
01 / CARTONSFOLD + GLUE

Straight tuck

Everyday carton with two tuck lids and a glue tab.

80 × 60
× 40 mm
02 / CARTONSFOLD + GLUE

Drawer and sleeve

Open cross-net drawer in a separately dimensioned sleeve.

80 × 60
× 40 mm
03 / RIGID SHEETEXPERIMENTAL · NO GLUE

Finger-joint box

Slot-fit rigid box with finger joints and a removable lid.

80 × 60
× 40 mm
04 / CARTONSFOLD + GLUE

Gable box

Gabled roof folds into a pierced handle bridge.

80 × 60
× 40 mm
05 / PAPERCRAFTFOLD + GLUE

Regular pyramid

Regular polygon base surrounded by congruent triangular faces.

65 × 65
× 90 mm
06 / ENVELOPESFOLD + GLUE

Letter envelope

Four-flap envelope with editable overlap and closure geometry.

140 × 95
× 25 mm
One project. Every piece.

Think it through.
Then make it real.

The drawing, the fold and the file share the same geometry. Change a dimension and your whole project follows.

Meet your new workbench
01

Make it your size.

Internal, external and flat dimensions. Always explicit.

02

See how it comes together.

Fold by fold. Panel by panel. At your own pace.

03

Take it to your workbench.

Actual-size vectors, tiled printouts and a recipe to keep.

A preview is a possibility. A measured test makes it yours.

Measure before making
